Before starting the discussion on what is ASIC and what is FPGA, we will first learn about the basics that a VLSI enthusiast should know. Moore’s Law: Moore’s law is the observation that the number of transistors in a dense integrated circuit doubles about every two years.

Power is one of the most concerned factor in the lower node technologies due to sophisticated operation of a system at higher frequencies, complex functionalities, wireless applications and portability. Power dissipation has become one of the critical issues as it results in heating up of the device which in-turn affects the operation of a chip.

The LEF file is the abstract view of cells. It only gives the idea about PR boundary, pin position and metal layer information of a cell. To get the complete information about the cell, DEF (Design Exchange Format) file is required. In this 3 sections are defined, i.e. technology, site, macros. In the technology part layers, design rules, via definitions and metal capacitance are defined.
